Description
Specifications
Max Working Pressure | 470 psi |
Pipe Diameter | 1-1/2 in. |
Pipe Length | 20 ft. |
End Connection | Plain End |
Minimum Working Temperature | 33° F |
Maximum Working Temperature | 140° F |
Schedule | Schedule 80 |
Material | PVC |
Color | Dark Gray |
Wide line of Solvent Weld includes PVC Schedule 40 (ASTM D1785 and ASTM D2665) and 80 (ASTM D1785) for both pressure and non-pressure applications. The pipes are available in 10 and/or 20 ft. lengths, in 1/2 to 16 in. diameters in Schedule 40, bell end and 1/2 to 12 in. diameters in Schedule 80, plain end. JM Eagle's ASTM 1785 product also comes in a specially formulated PVC material to increase resistance to ultraviolet rays. Called SolarBlok, it comes in IPS, 20-foot lengths, in brown. Solvent Weld joints are designed to provide a rigid (or restrained) joint connection and the schedule-rated products are specifically engineered for use in partial support systems above ground. A 20 ft. length of Solvent Weld Schedule 40 PVC water pipe weighs approximately 72 pounds.
