Specifications
Brand | Regency Wire |
Conductor Material | Soft Drawn Bare Copper |
Insulation Material | PVC |
Jacket Material | Polyethylene |
Number of Conductors | 2 |
Solid/Stranded | Solid |
Wire Gauge | 14 AWG |
Wire Roll Length | 1000 ft. |
Regency Wire Maxi Communication Cable, 14/2 1000' PVC Gauge size: 14 AWG Conductors Tin coated, soft drawn bare copper (ASTM Spec. 33). Two (2) conductors Solid (14 awg and 12 awg) Length: 2500' Color: Yellow Features and Benefits Regencys Maxi Cable is manufactured for the control of Rain Birds Maxi control systems. It is direct burial rated. Conductor construction is tin coated, soft drawn bare copper meeting the requirements of ASTM Specification 33. The two conductors shall be insulated with a high quality Polyvinylchloride (PVC) for system applications up to 600V. One conductor will be insulated black and the other conductor insulated red. Both conductors shall be of the same size as specified and/or shown on the drawings and as required for the proper operation of the Satellite and Decoder units connected to it. The two conductors shall be laid parallel and pressure extruded with a solid color, low linear density, sunlight resistant polyethylene (HDPE) outer jacket. The jacket comes in a variety of colors to accommodate easy identification. Comes with pull cord for easy stripping. Product Details Temperture: 60 °C Voltage: 600 V Insulation: Polyvinylchloride (PVC) Outer Jacket: Polyethylene (PE)
