14/2 1000' PVC Yellow Maxi Communication Cable | WIC1402MC1000Y

Specifications

Brand	Regency Wire
Conductor Material	Soft Drawn Bare Copper
Insulation Material	PVC
Jacket Material	Polyethylene
Number of Conductors	2
Solid/Stranded	Solid
Wire Gauge	14 AWG
Wire Roll Length	1000 ft.

Regency Wire Maxi Communication Cable, 14/2 1000' PVC Gauge size: 14 AWG Conductors Tin coated, soft drawn bare copper (ASTM Spec. 33). Two (2) conductors Solid (14 awg and 12 awg) Length: 2500' Color: Yellow Features and Benefits Regencys Maxi Cable is manufactured for the control of Rain Birds Maxi control systems. It is direct burial rated. Conductor construction is tin coated, soft drawn bare copper meeting the requirements of ASTM Specification 33. The two conductors shall be insulated with a high quality Polyvinylchloride (PVC) for system applications up to 600V. One conductor will be insulated black and the other conductor insulated red. Both conductors shall be of the same size as specified and/or shown on the drawings and as required for the proper operation of the Satellite and Decoder units connected to it. The two conductors shall be laid parallel and pressure extruded with a solid color, low linear density, sunlight resistant polyethylene (HDPE) outer jacket. The jacket comes in a variety of colors to accommodate easy identification. Comes with pull cord for easy stripping. Product Details Temperture: 60 °C Voltage: 600 V Insulation: Polyvinylchloride (PVC) Outer Jacket: Polyethylene (PE)
