Hunter High Speed Golf Rotor 5" Full/Part Circle, SS | ST1600HSB

Specifications

Brand	Hunter
Spray Pattern	Full/Part Circle
Warranty	5 years
UPC	611698027653

Synthetic Turf Rotor ST1600HSB Pop up Height: 5" Radius: 107' to 165' Inlet Size: 2" BSP* *Use BSP t.o.e. nipple adapter p/n 241400SP if desired Features and Benefits The ST-1600-HS-B pop-up rotor is ideal for expansive synthetic turf irrigation applications such as football, field hockey, and soccer fields. Its high-speed capability also keeps temperature under control for better playability. Designed for seamless installation, powerful performance, and easy servicing, it's also the most reliable gear-driven synthetic turf rotor on the market. This high-speed, pop-up model provides rotation speeds up to 65 seconds at a 180° arc setting with 120 PSI operating pressure for quick wetting where temperature control is needed. If desired, the rotation speed can be slowed by using the manual speed adjustment knob. Product Details Overall Height: 22 ½ " Exposed Diameter: 14" Flow: 96.2 to 326.8 GPM Operating pressure range: 60 ”“ 120 PSI Precipitation rate: 2.25 in/hr approximately Warranty period: 5-year component part warranty Proven isolated, grease-lubricated gear drive delivers consistent, top performance Flexible arc adjustment from 40° to non-reversing 360° with left and right movable stops makes it easy to set a precise arc Ratcheting nozzle turret for simple setup Adjustable speed of rotation up to 65 seconds enables quick wetting where temperature control is needed Stainless steel and brass internal construction for long-term reliability Six nozzle choices included from #16 to #26 (#20 standard) with 25° trajectory for choosing the perfect option ST-1600 Nozzle Performance Data Nozzle Pressure PSI Radius ft. Flow GPM Precip in/hr 16 60 107 96.2 1.63 1.88 75 115 107.3 1.57 1.81 90 121 117.8 1.54 1.78 105 128 127.3 1.50 1.73 120 135 137.4 1.46 1.69 18 60 112 107.0 1.66 1.91 75 121 119.4 1.56 1.80 90 128 131.0 1.54 1.78 105 133 141.3 1.54 1.78 120 141 153.2 1.48 1.71 20 60 115 144.0 2.10 2.43 75 128 160.9 1.89 2.18 90 141 176.5 1.71 1.97 105 144 190.5 1.76 2.03 120 148 204.2 1.80 2.08 22 60 118 171.5 2.37 2.73 75 130 191.8 2.20 2.54 90 144 210.0 1.94 2.24 105 154 226.9 1.84 2.12 120 157 243.1 1.89 2.18 24 60 121 202.1 2.64 3.05 75 133 225.9 2.46 2.84 90 148 247.6 2.19 2.52 105 156 267.4 2.12 2.45 120 160 286.4 2.16 2.49 26 60 126 233.2 2.83 3.27 75 136 260.4 2.71 3.13 90 151 284.5 2.40 2.77 105 160 307.0 2.31 2.67 120 165 326.8 2.32 2.68 Note: All precipitation rates calculated for 180 degree operation. For precipitation rate of 360 degree sprinkler divide by 2.
