Description
Specifications
Brand | Rain Bird |
Case Quantity | 250 |
Nozzle Trajectory Angle | 5° |
Nozzle Radius | 5 ft. |
Nozzle Spray Pattern | Quarter Circle |
Nozzle Type | Spray Nozzles |
For Use With | All Rain Bird® Sprinklers and Shrub Adapters |
UPC | 753800006320 |
Rain Bird, MPR Quarter Circle Nozzle 5 ft 5Q 5 ft. quarter-circle pattern MPR nozzle Fixed Spray Pressure: 15 to 30 PSI Features and Benefits Trusted for decades, Rain Bird® MPR Nozzles are installed by more contractors than all other brands combined. MPR Nozzles simplify the design process by allowing sprinklers with various arcs and radii to be mixed on the same circuit while maintaining even water distribution rates. They fit all Rain Bird spray heads and shrub adapters. Matched precipitation rates across sets and across patterns in 5 Series, 8 Series, 10 Series, 12 Series, and 15 Series for even water distribution and design flexibility Blue fine-mesh (.02" x .02") filter screens (shipped with nozzles) maintain precise radius adjustment and prevent clogging Stainless steel adjustment screw to adjust flow and radius Fits all Rain Bird sprinklers and shrub adapters Meets small-area shrub or turf requirements Product Details Spacing: 3 to 20 feet (0.9 to 4.6 m) Optimum pressure: 30 psi (2.1 bar) *Recommends using 1800 PRS spray heads to maintain optimum nozzle performance in higher pressure situations.
