Description
Specifications
| Brand | Febco |
| Body Material | Lead-Free Cast Copper Silicon Alloy |
| Connection Size | 1/2 in. |
| Connection Type | Threaded |
| Inlet to Outlet Length | 3-1/8 in. |
| Master Valve Status (Normally Open/Normally Closed) | 1/4 Turn Open/Close |
| Opening | Full Port |
| Operator Type | Tee Handle |
| Seat Material | PTFE |
| Stem Material | Brass |
| Top to Inlet Center | 1-7/16 in. |
| Valve Type | Ball Valve |
| UPC | 098268504972 |
Series LF622F lead free full port ball valves are designed for steam service applications. They are ideal for throttling and balancing of nonabrasive fluids where minimum flow is 20% to 100% of valve capacity. The full port design ensures minimal pressure drop. These valves feature a PTFE stem packing seal, thrust washer and seat. They are available with tapped outlets suitable for the installation of a pressure gauge or test cock. Maximum working pressure: 600psi (41.3 bar) WOG; 125psi (8.6 bar) WSP.
