Description
The Light Controller is a dual-channel device designed to control up to 40 fixtures or ballasts per channel. It can be utilized to manage fixtures in two independent rooms or control up to 80 fixtures in a single room. Additionally, when paired with an External Contact Module (ECM), auxiliary equipment can be controlled. Up to two ECMs can be connected to the controller. An alarm feature can be configured to trigger in case of a temperature shutdown or power outage (alarm sold separately).
Technical Specifications:
- Controller Dimensions (LxWxH): 4.33 x 2.55 x 0.82 inches / 110 x 21 x 65 mm.
- Power Supply:
- Adapter: 100V-240V AC 50/60Hz
- 15DC (1000mA)
- Maximum Control Voltage: 11.5V
- Maximum Voltage/Current Alarm Contacts (NO/NC): 13.5V/50mA
- Maximum Cable Length Per Port:
- 328ft / 100m.
- 820ft / 250m.
- Maximum Number of Ballasts Per Port: 40 (250* when using a repeater bus fixture or ballast)
- Total Number of Ballasts Per Controller: 80 (500* when using a repeater bus fixture or ballast)
