Duct Mounting Styles – Comprehensive Installation Options for Textile Diffuser Systems

Suspension and Surface-Mount Installation Styles

1. Single Cable
   • Description: A straightforward single-wire suspension system for lightweight diffusers.
   • Best For: Smaller or lightweight duct installations.
2. Suspension Mounted Single Track
   • Description: A single aluminum track profile suspended from the ceiling.
   • Best For Applications needing alignment away from the ceiling surface.
3. Surface Mounted Double Track
   • Description: Two parallel tracks mounted directly to the ceiling, providing additional stability.
   • Best For: Larger ducts or ducts needing a secure, low-profile mount.
4. Suspension Mounted Double Track
   • Description: Dual-track system suspended for stability in larger spaces with higher ceilings.
   • Best For: Large-scale installations where strong support is required.
5. Suspension Mounted Half Round
   • Description: Half-round diffuser mounted with suspension, ideal for areas with low ceilings.
   • Best For: Spaces where a low profile is necessary but some drop from the ceiling is acceptable.
6. Suspension Mounted Rectangular
   • Description: Rectangular ducting mounted by suspension for large or open spaces.
   • Best For Spaces with both high ceilings and a need for increased airflow control.
7. Double Cable
   • Description: Two-wire suspension system for additional support and stability.
   • Best For: Heavier or larger duct installations requiring extra support.
8. Surface Mounted Single Track
   • Description: Single track mounted directly on the ceiling surface for a low-profile installation.
   • Best For: Smaller or lightweight ducts requiring a straightforward ceiling-mounted installation.
9. End Cap Mounting
   • Description: Cap mounted at the end of the duct to secure the final portion of the diffuser.
   • Best For: Any duct system that requires secure endpoint closure and support.
10. Surface Mounted Half Round
    • Description: Half-round ducting mounted directly to the ceiling.
    • Best For: Low ceiling applications where airflow is needed without much drop from the ceiling.
11. Surface Mounted Quarter Round
    • Description: Quarter-round duct mounted at the ceiling-to-wall junction.
    • Best For: Compact areas such as offices where space efficiency and unobtrusive airflow are essential.
12. Surface Mounted Rectangular
    • Description: Rectangular ducting installed directly on the ceiling surface.
    • Best For Spaces needing a high-efficiency, low-profile duct system.

Choosing the Right Mounting Style

Factors influencing the best mounting style include:

• Ceiling Height: Surface-mounted options suit lower ceilings, while suspension is ideal for high ceilings.
• Duct Size and Shape: Larger or heavier ducts may require a double track or double cable for stability.
• Space Requirements: Half-round and quarter-round mounts save space in compact areas, and rectangular ducts are ideal for even air distribution in large rooms.

Each mounting style can be tailored to the unique needs of the installation space, ensuring efficient airflow, stability, and aesthetic harmony with the room’s design. Prihoda’s diverse mounting options provide robust solutions for any environment, from offices and classrooms to large industrial and commercial spaces.
