Valumax 5800xtr2 - Electronic Touch Screen Metered Control

Smart Valve Technology-includes a bypass valve-600NXT/SE Electronic Touch Screen Metered Water Softener The Valumax 5800 ecs2 is a low cost, high quality 24,000 grain capacity water softener designed for the budget minded person who doesn’t want to have to purchase another water softener for a very long time. Distinguished by its additional two-mode electronic controller, these controls were derived from the genesis of time clock and meter initiated systems; thereby, this system was built from proven technology of the past two decades and can deliver a variety of system capacities from 0.75 to 3.0 cubic feet (24K to 90K grains), providing installers options during sizing and configuration.

Its sophisticated touch screen, a wide range of regeneration types, and real time flow monitoring features give it an edge as a premium water treatment solution. No matter you have light residential use or heavy commercial use, you get the water system conditioning efficiency at every cycle with intelligent monitoring.

Interactive LCD Touchscreen

Simplified Navigation and Control

Full color T461-B STAND ALONE LCD touch screen provides easy access to system menu's, settings and diagnostics. Fledgling users can even control system settings easily with the simplified interface.

Password-Protected Settings

The computer can be password locked to restrict access to or modification of programming. This extra layer of protection safeguards critical configuration from accidental changes and reduces unnecessary service interriptions.

USB Integration and Diagnostic Intelligence

Smart USB Access

USB Programmable- Full USB programmability (uploads configurations quickly and downloads diagnostic logs with ease) Aside from convenience and simplicity, USB programmability is going to save time and money. USB connectivity allows service personnel to view water usage data, event logs and flow statistics which in turn helps provide faster, more informed service.

Real-Time Diagnostics

Its tracked metrics provide a comprehensive understanding of the system performance:

• Current flow rate
• Peak flow rate (resettable)
• Daily use in last four weeks
• Regeneration frequency and intervals
• Last regeneration data
• Usage since last regeneration
• Program change logs
• Totalizer value (resettable)

Municipal Key Metrics for operators to manage water usage based on data in order to keep an eye on trends in water use.

Versatile Regeneration Controls

Multiple Regeneration Modes

The system accommodates:

• Meter Delayed
• Meter Immediate
• Time Clock
• Volume Override Delayed
• Volume Override Immediate

This modularity makes the system flexible and able to meet individual user requirements, both for water saving and peak performance.

Customizable Flow Options

The Valumax 5800XTR2 is capable of Various flow patterns

• Downflow and upflow
• Upflow variable fill
• Downflow double backwash
• Filter and upflow filter
• Custom upflow and custom downflow

This means that it works well with almost all the latest water filtration and softening systems.

Reliable Performance and Power Resilience

Battery Backup for Power Loss

An inbuilt lithium battery prevents power interruptions from stopping the system clock. Time-based features remain functional, even during prolonged power outages, minimizing the risk of inaccurate display or lost data.

Service Reminders and Support Screen

The user features an assistance screen that includes a service dealer contact information and is programmable for service interval with an alarm. This prevents downtime and enhances performance even further with system alerts.

Key Specifications

• System Type: 4
• Valve Type: 5800
• Specifications: Electrical Rating: 12V DC (unique to the 5800 series)
• Capacity: 24K up to 90K grain
• Tank Sizes: RT8X44 to RT14X65
• Gallon Brine Tank: BT14X34 through BT18X40

Final Words

If what you want is a smart, modern, and very versatile water conditioning control unit, the Valumax 5800XTR2 gives you all of that. With an easy to use touchscreen interface, high efficiency but packed with features such as advanced diagnostics, multi-mode regeneration and USB programming, the Control Valve has been designed with you in mind for a reliable, easy and customisable water control. It is a reliable answer for water professionals and offers the general consumers an affordable, steel vessel option.
