50L Aerosol Extraction System - PURE5™

Extraction Vessel

• Volume: 2x25L vessel holds up to 6-8 lb of dry material
• Pressure: Maximum operating pressure 12 bar
• Temperature: Max 45°C/113°F
• Material: 304 stainless steel
• Vessel: interior is polished to food grade level
• Closures: ASME flange
• Sealing: Flanges with PTFE flat seals
• Temperature measurement: Pt100 sensors
• Water Jacket volume: 15 Liters (4 gallons)
• Safety: spring loaded safety relief valve
• Raw material feed: top loading
• Residue removal: flange closure, manual

Separator/Collection Vessel

• Separator: Jacketed separator/collection vessel
• Volume: 40 Liters (10,6 gallons)
• Pressure: Maximum pressure 12 bar
• Temperature: max 60°C (140°F)
• Materials: 304 stainless steel
• Safety: Spring loaded safety release valve
• Flow path: Continuous diameter with no constrictions

Heat Exchanger

• Construction: Refrigeration unit
• Materials: All 304 stainless steel
• Cooling/Heating: R404a refrigerant

Chiller/Receiver

• Refrigeration: heat pumping
• Temperature range: -10°C to 50°C (14°F to 158°F)
• Maximum refrigerant content: 65 kg

Skid Physical Dimensions

• Height: 1550 mm
• Length: 1750 mm
• Depth: 800 mm
• Total Weight: app. 1000 kg
• Floor mounting area: min 10 m²
• Ceiling height: 2.5 m

Control System

• Functions: Fully automatic programmable Logic Controller (PLC) touch screen interface with first level safety functionality and user programmable pressure, temperature, and time.
• Safety: Pressure transducers monitor system pressure and shut down system to prevent accidental over-pressurization.
