60L Super Heated Water System - PURE5™

Extraction Vessel

• Volume: 2×30 L vessel holds up to 15 pound of dry material
• Pressure: Maximum pressure 16 bar
• Temperature: max 200C (392F)
• Materials: 304 stainless steel
• Vessel: interior is polished to food grade level
• Closures: ASME valves
• Sealing: PTFE seals
• Temperature measurement: Pt100 sensors
• Safety: spring loaded safety relief valve

Water Heater

• Orientation: horizontal
• Pressure: Maximum pressure 16 bar
• Maximum water content: 35L

Gas Vessels

• Volume: 2×10 Liter
• Pressure: Maximum pressure 10 bar
• Temperature: max  60C (140F)
• Materials: 304 stainless steel
• Safety: spring loaded safety relief valve
• Flow path: gravitational path

Heat Exchanger

• Construction: heat exchanger unit
• Materials: all 304 stainless steel
• Heating: Heat Exchange

Physical Dimensions

• Height: 1,550mm
• Length: 1,420mm
• Width: 780 mm
• Total weight: 550 kg

Electrical

• Voltage: 230V
• Power: 10 kW
• Plug: 4-way 50A outlet

Control System

• Functions: Fully automatic programmable Logic Controller (PLC) touch screen interface with first level safety functionality and user programmable pressure, temperature, and time.
• Safety: Pressure transducers monitor system pressure and shut down system to prevent accidental over-pressurization/safety valves.
